Digital Rolling Rail Gauge
Digital rolling gauge main for railway main line track gauge and cant measurement.Could be used for track maintenance department to temporary inspection and fine adjustment.Save the measure data through the smart display. This product has fast measuring speed, push rod can be stored, the implementation process is stable, easy to carry, can be used during the day and night It is an ideal equipment for all kinds of track fine adjustment, track construction inspection, track laying and line operation after opening.
- Product Introduction
Product Description
Digital rolling gauge main for railway main line track gauge and cant measurement.Could be used for track maintenance department to temporary inspection and fine adjustment.Save the measure data through the smart display. This product has fast measuring speed, push rod can be stored, the implementation process is stable, easy to carry, can be used during the day and night It is an ideal equipment for all kinds of track fine adjustment, track construction inspection, track laying and line operation after opening.
Technical Parameter
Scope of use
1000mm track gauge：（1505-1550）mm；
Cant：（-185～＋185）mm；
Display：OLED，Smart display on the handle；Voltage：DC3.4V～5.2V（rechargeable；
Work temperature：-30℃～+55℃；
Track gauge resolution：0.01mm；
Cant resolution：0.05mm；
Track indication：±0.25mm；
Cant indication：±0.3mm；
Insulation Performance：＞1MΩ；
Weight：≈6.5kg；
Length：＜1700mm
Feature
1、Gauge body；2、Display；3、Handle；4、Insulating sheath；5、Running wheel；6、Measure wheel；7、Push rod(with bluetooth button)；
