Railway Tool Rail Striking Equipment
The ZGC Rail striking equipment is an auxiliary tool for the DGQ rail striking device. The machine is simple to operate, sturdy and durable, easy to use, and small in size. It is an ideal tool for railway laying operations.
- Product Introduction
1.Scope of application
The ZGC Rail striking equipment is an auxiliary tool for the DGQ rail striking device. The machine is simple to operate, sturdy and durable, easy to use, and small in size. It is an ideal tool for railway laying operations.
2.Main Technical Parameters
1. Machine Weight: 276kg
2. Dimension:2000*300*195mm
3. Working Principle and Basic Structure
The basic structure is shown in the figure: it is composed of frame, pulley and earring.
4.Usage and Maintenance
1. Clamp the rail with rail striking crashed device on the same rail, leave a proper distance, hang the ear ring on the hit rail vehicle with the traction rope (firmly), and strike 4-6 people or more people towards the rail crashed at the same time to achieve the purpose of stress relief.
2. Regularly maintain the pulley part of the rail striking equipment.
5.Attention
1. When installing the card, the left and right card bodies must be closely attached to the rail palate to prevent the "slipping" phenomenon when hitting the rail, and the force of the operator must be consistent.
2. It is better to choose the special DGQ type rail striking device produced by our factory.
3. In case of rail collision, the power shall be cut off and the vehicles shall pass through. Pay attention to the personal safety of operators.
