- Product Introduction
portable rail grinding machine
At present, there are a variety of small grinding machines in China, most of which are manually controlled, and the grinding head is driven by gasoline internal combustion engine or electric power, which is extremely inefficient and can only be used for small-scale and small-scale track repair work. In terms of copying technology, the contact copying between the mechanical roller and the track surface on the original track, coupled with manual adjustment of the grinding amount, the grinding surface cannot be standardized.
In the railway workers use internal combustion portable grinding machine grinding rail, after the use of a lot of people do not know how to maintain the machine, it is inevitable that the use of life will be shorter, today JinZhou tiegong teach you some of the internal combustion portable grinding machine maintenance methods.
Portable rail grinding machine is suitable for all types of rail grinding treatment, its small size, flexible and lightweight, simple operation, high grinding efficiency, easy to carry, easy to maintain and repair, but also suitable for other occasions.
|
Type |
Parameter |
|
SNGM-180 |
1. Internal combustion engine: Model: Two-stroke gasoline engine Power: 1.47kW Speed: ≥8500r / min 2. Grinding wheel: ∮ 180 × ∮22.2 × 6 Or ∮ 150 × ∮ 22 × 6 3. Wheel speed: ≥ 70m / s 4. The spindle speed: ≥ 6000r / min 5. Sie: 780 × 270 × 310mm 6. Machine weight: 7kg |
The following are the maintenance methods of the internal combustion portable sanding machine:
1, after the internal combustion portable sander has run for 500 hours in total, it should be disassembled to clean the bearings and replace the high-speed grease. (Note: The grease must not be added too much, so as not to overflow during operation, which will lead to the failure of belt slipping).
2,If the internal combustion portable sander is weak in sanding, you need to adjust the belt loosening and tightening through the adjusting bolt.
3, in the process of using and transporting the internal combustion portable sanding machine, hold it gently and put it down.
4, not used for a long time, the machine should be placed in a ventilated, dry, no corrosive gases in the warehouse, the internal combustion engine should be drained of fuel.
5, the sanding wheel disc should pay attention to moisture, collision, pressure, in the sanding wheel disc moisture must not be used.
6, petrol engine recommended operation of the ambient temperature between -15 ℃ ~ 40 ℃.
7,The internal combustion portable sander is a two-stroke petrol engine, and the mixture of oil should be matched strictly according to the instruction manual of the petrol engine. When filling the fuel, the engine should be stopped and away from the fire source, and after refuelling, the surface of the machine should be wiped clean of residual gasoline before starting, otherwise it will cause damage to the machine at your own risk.
