Petrol Engine Rail Bolt Wrench
1. Main features (1) The machine adopts Husqvarna 555 petrol engine as power, strong power, high working efficiency; (2) Compact and reasonable structure, beautiful appearance, easy to carry and comfortable to operate; (3) Safe to use and easy to maintain. 2. Main applications (1) In railway maintenance, it is suitable for various types of concrete sleeper bolts loosening and unloading fastening operations, especially can be used in no external power supply, no external pneumatic power occasions on the sleeper bolts to install or dismantle; (2) By replacing different sleeves, the machine can also be used for cracking or fastening other bolts of sleepers;
- Product Introduction
1. Product introduction
1. Main features
(1) The machine adopts Husqvarna 555 petrol engine as power, strong power, high working efficiency;
(2) Compact and reasonable structure, beautiful appearance, easy to carry and comfortable to operate;
(3) Safe to use and easy to maintain.
2. Main applications
(1) In railway maintenance, it is suitable for various types of concrete sleeper bolts loosening and unloading fastening operations, especially can be used in no external power supply, no external pneumatic power occasions on the sleeper bolts to install or dismantle;
(2) By replacing different sleeves, the machine can also be used for cracking or fastening other bolts of sleepers;
2. Technical parameters
|
Product Name |
Internal Combustion Rail Bolt Wrench
|
|
|
Engine |
Engine Model |
Husqvarna 555 |
|
Type |
Single-cylinder, air-cooled, two-stroke, AutoTune (electronically adjusted to ensure that the machine can be adapted to all practical conditions, such as different weather, altitude, petrol and two-stroke oil types). |
|
|
Displacement |
59.8 |
|
|
Maximum output power kW /r/min |
3.1/9600 |
|
|
Fuel consumption g/kW-h |
≤438 |
|
|
Silencer mounting structure |
Embedded mounting structure, reduce vibration shear force, reduce the damage rate, but also can minimise the noise. |
|
|
Cylinder cover fastening method |
Simple buckle mounting structure, easy maintenance and dismantling, no tools required. |
|
|
Working weight kg |
19 |
|
|
Dimension of square tenon mm |
25.4 |
|
|
Tightening torque N.m |
≥1200 |
|
|
Loosening torque N.m |
≥1800 |
|
|
Machine working speed r/min |
700 |
|
|
Idling speed of petrol engine r/min |
2800±200 |
|
|
Oil tank volume L |
0.65 |
|
|
Impact system lubricant |
40#engine oil |
|
|
Outer size mm |
680×465×300 |
|
If you want to know more details,please don't hesitate to contact me!
