Smart Mini Battery Rail Trolley
This rail trolley is suitable for transporting small tools on track rails. It is suitable for 1435mm rail gauge (it can also be designed according to customer requirements). It must run on blocked track lines (for maintenance time) or lines without trains. It is equipped with lithium battery pack as the power source. Please notice that the trolley is not a rail wagon, it can’t be driven too fast and the driving speed can’t exceed 6km/h, and also the driving speed in the curve and turnout area shall not exceed 5km/h. In case of danger due to overspeed, the consequences shall be borne by yourself.
- Product Introduction
Scope of Application
This rail trolley is suitable for transporting small tools on track rails. It is suitable for 1435mm rail gauge (it can also be designed according to customer requirements). It must run on blocked track lines (for maintenance time) or lines without trains.
It is equipped with lithium battery pack as the power source. Please notice that the trolley is not a rail wagon, it can’t be driven too fast and the driving speed can’t exceed 6km/h, and also the driving speed in the curve and turnout area shall not exceed 5km/h. In case of danger due to overspeed, the consequences shall be borne by yourself.
Main Technical Parameters
1. Driving speed: ≤ 7Km/h
2. Motor type: DC brushless reduction motor
3. Rated output power of motor: 0.8Kw
4. Rated voltage of motor: 48V
5. Battery voltage and capacity: 48V/50AH
6. Charging time: 6 ~ 8 hours
7. Output voltage: AC220V ±10% 50-60Hz
8. Charging voltage: 54.6V ± 0.4
9. Rang of one charge: winter ≥ 40km, summer ≥ 60km
10. Braking distance: 5 ~ 8m
11. Load capacity: ≤ 500kg
12. Trolley weight: ≤ 127kg
13. Dimension: 1000×1700× 400mm
