Internal Combustion Tilting Rail Grinding Machine Rail Grinder

Application Scope:

The machine is mainly used for grinding rail thermite seamless welding or strengthening welding and burr caused by rail wear. The machine body is made of high-strength aluminum alloy frame, equipped with inclined anti-skid guide wheel, which can grind both sides and top surface of rail head. It is a special equipment for rail head grinding in railway engineering.

Main Features:

(1) Use tilting engine, can tilt 90 degrees to grind continuously for more than 2 hours.

（2）仿形打磨，打磨精确，效率高，打磨面光洁。

(2) Profiling grinding, grinding accuracy, high efficiency, smooth grinding surface.

（3）自动锁紧结构，锁定打磨位置后能有效保持。

(3) Automatic locking structure, after locking grinding position, can be effectively maintained.

（4）机械进给，省力方便。

(4) Mechanical feed, labor saving and convenient.

Technical Parameters:

Weight (kg) Overall weight: 73±3kg

行走方式 手推式

Walking mode: Hand push

打磨位置调节方式 手轮螺旋调节

Adjustment mode of grinding position :Hand wheel screw adjustment

发动机功率 4.5kw/3800rpm

Engine power :4.5kw/3800rpm

砂轮规格 125*65*M20

Grinding wheel specification :125*65*M20

仿形轮距（mm） 1005±4

Profiling track width (mm): 1005±4

发动机型号 1P73F

Engine model: 1P73F

发动机燃油消耗率（g/Kwh） ≤460

Engine fuel consumption (g / kWh): ≤460

发动机排量（ml） 209

Engine displacement (ML): two hundred and nine

燃油箱容积（L） 1.0

Fuel tank volume (L) :one

翻转90°连续打磨时间（h） ≥2

Turning 90 ° continuous grinding time (H)： ≥2

机体与钢轨间绝缘（MΩ） 500

Insulation between body and rail (m Ω) five hundred

是否有侧边打磨辅助支架 可选装

Is there an auxiliary bracket for side grinding Optional
