Intelligent Hydraulic Rail Fat Edge Cutting Machine
This equipment is a new product integrating cutting, cooling, automatic running, electromechanical and hydraulic. It has the features of remote control function, high operation efficiency, convenient access, portable equipment, simple operation, reliable safety performance, etc.
- Product Introduction
Intelligent hydraulic rail fat edge cutting machine is mainly used for cold cutting of rail fat edge.
The whole machine adopts modular split structure, with light weight of single body, high degree of integration, easy access and easy operation.
Technical Parameters
1. Gasoline engine model: Briggs Stratton 25V3
2. Gasoline engine type: air-cooled four-stroke OHV
3. Rated torque of gasoline engine (N.m/r mp): 28.5/3600
4. Operation efficiency: ≥ 140m/h
5. Output voltage: 12V
6. Maximum system pressure: 20MPa
7. Fuel consumption of gasoline engine: 1.1L/km
8. Single piece weight: outer cylinder 28kgX2; Inner cylinder 21kgX2; Clamp concrete 28kgX3; Knife body 57kg; Pump station 120kg; Short oil pipe 1.3kgX4; Long oil pipe 1.6kgX4; 1.5kg for cooling part; The auxiliary support flatbed truck is 17kg.
9. Total weight: 386kg.
10. Overall dimension (length × wide × X height): 3100 × one thousand nine hundred and fifty × 800mm
Basic structure
Cutter body assembly 1 piece
6 body cutters
3 front, middle and rear clamps
2 cooling parts
Hydraulic cylinder
8 fixing pins of oil cylinder
1 hydraulic pump station
1 auxiliary support flat car
8 high-pressure rubber hoses
1 wireless remote control
Preparation before operation
1. Check whether the components of the intelligent hydraulic rail trimming cutter are complete and connected firmly, and the fastening screws should be tightened.
2. Check that the hydraulic oil in the oil tank of the hydraulic pump station is not less than 3/4 of the oil tank opening. The hydraulic oil shall be selected according to the use season and local temperature (generally 68 # or above is selected in summer, and 32 # is appropriate in winter).
3. Fill gasoline and gasoline engine oil according to the gasoline engine instructions.
4. Connect the components, start the gasoline engine, and observe whether the hydraulic parts have oil leakage.
5. According to the instructions, first test whether the conversion of each part works reliably. If there is any abnormal phenomenon, immediately shut down the machine for inspection. After the fault is eliminated, restart the machine for idling test. The running time shall not be less than 3 minutes.
6. Read the instructions carefully. Operate in strict accordance with the instructions.
